6 8 12 Nozzle Solid fuel burner for brick kiln firing

Home Page ▶ Products > dryerandkiln ▶ Detail

6 8 12 Nozzle Solid fuel coall burner for brick kiln firing
Category: [Dryer and Kiln]

Send inquiry Buy It

Description

Parameters

Video

The Nozzle Solid fuel burner is sprayed and automatically ignited, installed in the burning part of the kiln.

The burner is controlled by the temperature regulator and thermocouple homogenization temperature and optimized combustion. Each burner contains. manual shut-off valve, large flame solenoid valve, small flame solenoid valve, cast aluminum burner head, secondary air low pressure safety switch and pressure gauge, burner gun with a set of special materials telescopic tube. The electronic control unit is equipped with complete flame control, temperature regulator, thermocouple .

Parameters

Number of coal feeding ponits	6/8/12
Power of screw conveyor	0.37 Kw
Single burner CV	57600 Kcal
Solid fuel powder particle size	≤5mm
Coal moisture content	≤5%
Coal consumption at each buner	5-12 Kg/h
Max. flow at single feeding point	180 m3/h
Blower and crushing power	4 Kw
Voltage	220/380v/415 v
Auxiliary power supply	24V
Maximum working pressure	0,5 bar
Operating temperature	-10 to 50 °C
